Marine Automation Services
Technical support for electronically controlled engines, power management systems, and cargo control platforms. OEM-agnostic diagnostics.
Marine Automation Services
Advanced control systems diagnostics, PLC programming, and remote monitoring solutions.
Our automation engineers are trained in control logic, hardware interfacing, and fieldbus diagnostics – not just component swapping. We do not merely replace cards. We identify root cause: failed I/O, corrupted logic, earth fault, signal interference, or sensor drift.
Core Competencies
- ME Engine Control Systems (MES / DPS / FIVA)
- VRC calibration and performance optimization
- PLC and SCADA-based control systems
- Boiler and IGG burner management
- Switchboard, PMS, and generator load sharing
- Alarm monitoring and data logging systems
Electronically Controlled Engine Services
MAN B&W ME/ME-C/ME-B | Wärtsilä RT-flex / X | Sulzer Flex | Caterpillar M/E
FIVA / HPS / INJ
Valve response testing, spool replacement, LVDT calibration, null-adjustment
Control Units
CCU, ECU, DCU – fault code interpretation, firmware version verification
Hydraulic Power Units
Pump pressure setting, filter inspection, accumulator pre-charge
Crank Angle Sensors
Gap setting, waveform verification, replacement
Engine Safety System
Overspeed trip testing, shutdown logic validation, alarm setpoint verification
VRC & Combustion Optimization
VRC calibration is a distinct technical competency. Our engineers adjust fuel injection timing against crankshaft angle to optimize specific fuel oil consumption and reduce cylinder imbalance.
- VRC position sensor calibration
- Hydraulic servo deadband compensation
- Timing deviation measurement (per cylinder)
- Actuator linkage wear assessment
- I/O signal validation between VRC and engine control system
- Re-timing following camshaft removal or cylinder head replacement
Power Management & Electrical Control
1Power Management System (PMS)
Load-dependent start/stop, priority tripping, blackout recovery logic, breaker control
2Generator Control
Voltage regulator tuning, droop setting, synchronizing check relay calibration
3Switchboard
PLC I/O mapping, mimic panel diagnostics, earth fault location
4VFD & Soft Starters
Parameter verification, communications interface, fault logging
Specialized System Automation
Boiler, IGG & Thermal Fluid Automation
- Burner management system: Flame scanner validation, purge cycle timing, fuel valve leak testing
- IGG: Combustion air ratio control, deck seal monitoring, pressure control loop tuning
- Three-element feed water control: Drum level tuning, flow transmitter verification
- Alarm and trip testing: Low-low water level, flame failure, high steam pressure
Cargo, Ballast & Valve Remote Control
Cargo Control
Loading computer interface, tank level monitoring (radar/servo), valve remote control system, pressure and temperature transmitter loop validation
Ballast Control
Remote valve actuation, tank level sensing, bilge system automatic start logic
Safety Systems
Fire and gas detection panel, ESD logic testing, PA/GA system integration
Cargo Tank Gauging Systems
Radar, servo & ultrasonic level measurement – repair & calibration. Our engineers diagnose and repair the instrumentation itself, including PCB-level electronics.
Tank Gauging Scope
- Radar gauge: Transceiver diagnostics, antenna cleaning, echo profile verification
- Servo gauge: Motor driver board repair, wire drum replacement, encoder calibration
- Ultrasonic gap gauges: Transducer replacement, signal conditioning board repair
- PCB-level repair: Power supply boards, processor cards, display units, I/O modules
- Sensor loop validation: 4-20mA, fieldbus, serial interface
Remote Diagnostics & Condition Monitoring
Remote Support Capabilities
Our engineers access control systems remotely to perform first-line fault analysis prior to mobilization.
- PLC program upload/download and force monitoring
- Trend logging of analogue process values
- Alarm history retrieval and sequence-of-events analysis
- Firmware version verification
- Pre-mobilization spare part recommendation
Onboard Condition Monitoring
- Cylinder pressure analysis
- Vibration signature collection (turbocharger, main engine crosshead)
- Bearing temperature trend monitoring
- Exhaust gas temperature deviation logging
Need Automation Support?
Remote diagnostics available 24/7. Our automation engineers are ready for deployment worldwide.
